A high torque motorised bolt that moves from the vertical position to the horizontal state when locked.

SKU:30690


Vendor Part No: ES8100

Test 1

Test 2

Overview

Details

The bolt moves into the V shaped strike plate pulling the door aligned with the lock. The high torque motorised bolt can be concealed from view or surface mounted and has the worlds first fail-open motor locking mechanism. Slim design with classic satin stainless steel faceplate, and significant 7mm overall (+/- 3.5mm) door misalignment tolerance make ES8000 a product with great aesthetic appearance as well as easy installation.

Key Features

  • SIDE LOAD - PRE LOAD Capable
    Lock will unlock with up to 15kg of side pressure, when wired in 3 wire mode. (1 x Permanent Power, (positive 12-24Vdc) wire. Negative (0 volt return) wire, and 1 x Switching input (positive 12-24Vdc) wire
  • Door misalignment of up to 3.5mm +/-
  • Power to Lock (Fail Safe) / Power to Open (Fail Secure) field configurable
  • HIGH TORQUE Motorised locking and unlocking (3 wire mode)
  • High Speed Operation. Unlocks in less than 1 second
  • Surface Mount Accessory Kit. Ideal for 180° swing through glass door applications
  • Multiple Orientation - Interior Doors Can be mounted vertically or horizontally (For exterior doors due to possible water ingress the ES8000 must be mounted horizontally)

Applications

  • Misaligned doors
  • Timber doors
  • Glass doors
