Key features:
- Operates under pre-load up to 100 lbs.
- Automatic dual voltage - no field adjustment required
- Manual key override (right or left hand)
- Self-aligning receiver (+/- 1/2" horizontally) helps compensate for gate misalignment and sag
- Tamper proof cast housing
- Latch status monitor switch (SPDT)
- Heavy wall 1/2" inside diameter threaded steel coupling
- Surface Mount
- Black finish
- Holding Force: 2000 lbs. [907 kg]
- Current Draw and Voltage:
- 12 Volts Initial (Peak): (~1.0 sec.) at 870mA - Reduced: 290mA / Power Consumption: 3.5 Watts
- 24 Volts Initial (Peak): (~1.0 sec.) at 720mA - Reduced: 170mA / Power Consumption: 4.1 Watts - Operating Temperature: -58 to +167F [-50 to +75C]
- Warranty: MagnaCare Lifetime Replacement Warranty
